Размеры волноводных фланцев по стандарту IEC
(International Electrotechnical Commission)

Тип волновода;Рабочий диапазон частот, ГГц;Тип фланца;3D-модель (STEP)

WR-510;1,45 - 2,2;UG-1717/U link=#rec271681373;WR-510_UG-1717U.STEP button=https://yadi.sk/d/NJpisIdJXuYHNg WR-430;1,70 - 2,60;UDR22 link=#rec266271098;WR-430_UDR22.STEP button=https://yadi.sk/d/eXOioPzAx-CYYQ WR-340;2,20 - 3,30;UDR26 link=#rec270109586; WR-340_UDR26.STEPbutton=https://yadi.sk/d/Mr9K7Pd0XC1EGw WR-284;2,60 - 3,95;UDR32 link=#rec882028465; WR-284_UDR32.STEP button=https://disk.yandex.ru/d/jLpBA0HfihS8iQ WR-284;2,60 - 3,95;UER32 link=#rec270102270; WR-284_UER32.STEP button=https://yadi.sk/d/lrk9RPFMTyjZqg WR-229;3,30 - 4,90;UDR40 link=#rec278568196;WR-229_UDR40.STEP button=https://yadi.sk/d/lT1BDZ6YS2LMOg WR-229;3,30 - 4,90;UER40 link=#rec265710055;WR-229_UER40.STEP button=https://yadi.sk/d/M3tX6EFRbn5mAQ WR-187;3,95 - 5,85;UER48 link=#rec270019608;WR-187_UER48.STEP button=https://yadi.sk/d/6OaB47svd8Oxng WR-159;4,90 - 7,05;UER58 link=#rec269762768;WR-159_UER58.STEP button=https://yadi.sk/d/OPxbD4ID-fdZMQ WR-137;5,85 - 8,20;UDR70 link=#rec278572921;WR-137_UDR70.STEP button=https://yadi.sk/d/Q1VhAtJ9Q8cXQg WR-137;5,85 - 8,20;UER70 link=#rec266372410;WR-137_UER70.STEP button=https://yadi.sk/d/ztOKn-LND-WX_g WR-112;7,05 - 10,00;UBR84 link=#rec268507443;WR-112_UBR84.STEP button=https://yadi.sk/d/Ql2-BXkuBeGfUw WR-112;7,05 - 10,00;UER84 link=#rec268509168;WR-112_UER84.STEP button=https://yadi.sk/d/ZYZk4nI71-cR8g WR-112;7,05 - 10,00;PDR84 link=#rec715448345;WR-112_PDR84.STEP button=https://disk.yandex.ru/d/xC8F1F50MaYBHw WR-90;8,20-12,40;UBR100 link=#rec265134305;WR-90_UBR100.STEP button=https://yadi.sk/d/VwJhVTcDqZ4vWw WR-90;8,20-12,40;UDR100 link=#rec1586308421;WR-90_UDR100.STEP button=https://disk.360.yandex.ru/d/kv_L8X3WKOdrbg WR-90;8,20-12,40;UER100 link=#rec265700798;WR-90_UER100.STEP button=https://yadi.sk/d/ywrysRpqiokbpw WR-75;10,00 - 15,00;UBR120 link=#rec265702982;WR-75_UBR120.STEP button=https://yadi.sk/d/zkoCyzxEFt9IdQ WR-75;10,00 - 15,00;UER120 link=#rec265706752;WR-75_UER120.STEP button=https://yadi.sk/d/vbG5Yx4NbLbHuA WR-62;12,40 - 18,00;UBR140 link=#rec268800433; WR-62_UBR140.STEP button=https://yadi.sk/d/emlmRat2s9msMA WR-62;12,40 - 18,00;UER140 link=#rec268800624; WR-62_UER140.STEP button=https://yadi.sk/d/Mk1z8Oajf2XpHw WR-51;15,00 - 22,00;UBR180 link=#rec269678095;WR-51_UBR180.STEP button=https://yadi.sk/d/HrJFILInwhtrbQ WR-51;15,00 - 22,00;UER180 link=#rec269679081;WR-51_UER180.STEP button=https://yadi.sk/d/ZNMxwocwbsEGXw WR-42;18,00 - 26,50;UBR220 link=#rec268842017;WR-42_UBR220.STEP button=https://yadi.sk/d/c-2-uXT3G5Uo2A WR-42;18,00 - 26,50;UDR220 link=#rec268842792;WR-42_UDR220.STEP button=https://yadi.sk/d/0ok1DL1XGNERmg WR-34;21,70 - 33,00;UBR260 link=#rec268930542;WR-34_UBR260.STEP button=https://yadi.sk/d/LvKiFC-safqoBA WR-34;21,70 - 33,00;UDR260 link=#rec268931291;WR-34_UDR260.STEP button=https://yadi.sk/d/zZbtqJ31CHyfdg WR-28;26,50 - 40,00;UBR320 link=#rec269005345;WR-28_UBR320.STEP button=https://yadi.sk/d/P7jL3N6Pns9Yzg WR-28;26,50 - 40,00;UDR320 link=#rec269006488;WR-28_UDR320.STEP button=https://yadi.sk/d/Xi1r927q8VgKzA WR-22;33,00 - 50,00;UG-383/U link=#rec270898765;WR-22_UG-383U.STEP button=https://yadi.sk/d/YWxt80dh1wYJHQ WR-19;39,30 - 59,70;UG-383/U (мод.) link=#rec271279615;WR-19_UG-383U mod.STEP button=https://yadi.sk/d/h5sCceQaY_pYQA WR-15;50,00 - 75,00;UG-385/U link=#rec271289047;WR-15_UG-385U.STEP button=https://yadi.sk/d/6jfwtFVum-ggYg WR-12;60,5 - 92,0;UG-387/U link=#rec271392031;WR-12_UG-387U mod аналог.STEP button=https://yadi.sk/d/KpcbWC3pVffaXg WR-10;75,0 - 110,0;UG-387/U link=#rec271397099;WR-10_UG-387U mod аналог.STEP button=https://yadi.sk/d/W2zNHEpKqhPEDw WR-8;92,3 - 140,0;UG-387/U link=#rec271400074;WR-8_UG-387U mod аналог.STEP button=https://yadi.sk/d/1jbuPM7N6b0xOA WR-6;114,0 - 173,0;UG-387/U link=#rec271412549;WR-6_UG-387U mod аналог.STEP button=https://yadi.sk/d/F7n-IvzdFGh-vQ WR-5;145,0 - 220,0;UG-387/U link=#rec271416876;WR-5_UG-387U mod аналог.STEP button=https://yadi.sk/d/10jKteAoghYnmg WR-4;172,0 - 261,0;UG-387/U link=#rec271419927;WR-4_UG-387U mod аналог.STEP button=https://yadi.sk/d/OUeQ0zxtnrg6CA WR-3;217,0 - 330,0;UG-387/U link=#rec271435053;WR-3_UG-387U mod аналог.STEP button=https://yadi.sk/d/7G2lDuRgxytpMw
